6.2KVA Inverter and Battery ECCO Combo 48V ECCO 5.12 KWH Lithium Battery

Original price R 22,400.00 - Original price R 22,400.00
Original price
R 22,400.00
R 22,400.00 - R 22,400.00
Current price R 22,400.00
    Visa Mastercard mobicred Zapper Maestro PayFast Instant EFT
Availability:
in stock, ready to be shipped

Available Online & In-Store, Pay on Collection

Delivery Estimate 1-2 Business Days

6.2KVA Inverter and Battery ECCO Combo 48V ECCO 5.12 KWH Lithium Battery



6.2 Kva 620000w Hybrid Inverter 48v Mppt 120A Inverter Pure Sine Wave - Ecco


The main difference between PWM and MPPT charge control devices is that the MPPT devices are more efficient. MPPT charge control devices have 30 % more efficient in charge efficiency according to PWM type. Panel voltage and battery voltage should be matched in PWM systems.


Features
- Dual output for smart load management
- Lithium battery activation function by PV or Utility - Compatible work with LiFePO4 battery via RS485 - PV Input 500 Vdc Max
- Built-in MPPT 120A
- Capable to work without battery
- Detachable dust cover for harsh environment
- Wifi remote monitoring optional
- Support multiple output priority: UTL, SOL, SBU, SUB - EQ function to optimize battery performance and extend lifecycle

Specifications:

Dimensions ; 438 x 312 x 122
Weight : 11kg

It is recommended to use ECCO Batteries and Solar Panels for Quality Guaranteed Results.

Important Note: This product requires installation by a qualified PV installer, the PV installer must be able to issue a Certificate of Compliance. This is to ensure that the installation is safe and correct, as well as, within the scope of relevant regulations.

What's in the box
1 x ECCO 6.2KW Inverter
1 x Connecting Cables
1 x User Guide

  • 5-Year Repair Warranty

ECCO Lithium Ion Battery 51.2V 100AH 5.1KWH Wall Mounted

  • + Wall-mounted design, easy to install, and aesthetic
    + Adopts lithium iron phosphate battery cell, safe to use, long life cycle
    + Maximum 1C charge/discharge
    + User-friendly human-machine inter face
    + Compatible with multiple brands of inverters at the same time
    + Supports a maximum of 16 parallel groups
    + Meet North American UL, EU TUV standards

Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than a lead acid battery, helping to minimize replacement cost and reduce the total cost of ownership. Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries. Higher Power: Delivers twice the power of the lead acid battery, even high discharge rate, while maintaining high energy capacity. Wider Temperature Range: -20 C~60 C. Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging, or short circuit situations.

What's in the box:

Battery

Battery Cables & Mounts Included

Battery Parameters:

Battery Type is set to "USE."
Bulk Charge Voltage is set to 56.4-56.6V.
Float Charge Voltage is set to 54V.
Cut Off Voltage is set to 47V.

Specifications:

Nominal Voltage (V) 51.2
Nominal Capacity (Ah) 100
Total Power (kWh) 5.12
Best Operating Voltage Range (V) 43-54.5
Short Circuit Protection yes
Power-on Reverse Connection Protection optional
Maximum Charging Voltage (V) 57.6
Best Charging Voltage (V) 56.4 (recommended)
Maximum Continuous Output Power (W) 5500
Maximum Momentary Output Power (W) 7500
Local Parameter Configuration support
Max Installation Dimension (mm) 480*170*500
Package Size (mm) 590*290*615
Weight (kg) 49
IP Class IP 54
Communication RS485, RS232, CAN
Design Life 15 years

Warranties:

5 Years Warranty
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.



Package Includes:
1x Hybrid Inverter 48v 6.2 Kva 6200w MPPT 120A Inverter Pure Sine Wave - Ecco (5 Years Repair Warranty)
1x Ecco Lithium Ion Phosphate 51.2v 100ah 5.12 KWh Battery LFELI-51.2100  (Wall Mount) (5 Years Warranty)
